Digital Frequency Discriminator

2 - 6 GHz Digital Frequency Discriminator

Features

    • 2.0 - 6.0 GHz FREQUENCY RANGE
    • 100 nS to CW INPUT RF PULSE  WIDTH
    • EXTERNALLY TRIGGERED
    • 14 BITS FREQUENCY RESOLUTION
    • 100 nS RECOVERY TIME
    • SIZE: 5.9” x 4.69” x 1.5”

Description

AKON is a leading manufacturer of RF/microwave components and subsystems for military, space and commercial applications. AKON’s product line includes high reliability, custom integrated microwave assemblies, DFD receivers, microwave receiver front-ends, RF switching matrices, frequency synthesizers, custom LO assemblies, frequency converters, RF switches, digitally controlled attenuators, miniature RF filters and switches, and microwave amplifiers covering 2.0 - 18.0 GHz frequency range (up to 40.0 GHz for some applications). AKON is qualified to MIL-I-45208 Quality System Requirements by agencies of the U.S. Department of Defense and by leading foreign and domestic military OEMs. All specifications are valid over the full operating temperature unless otherwise indicated.

SPECIFICATIONS
Model Number A20-MH204
Frequency Range(GHz) 2.0-6.0
Unambiguous BW (MHz) 4800
Frequency Accuracy (MHz) ( RMS) 1.5 (max)
Frequency Resolution (MHz) 0.3
Mean Cell Width (MHz) 0.3 (nom)
Dynamic Range(dBm) -65 to +5
Sensitivity (dBm) -65
Signal Processing Capability Pulse (50 ns to CW)
VSWR 2.0:1 (max)
Input Impedence (Ohms) 50
Survival Power (dBm) +20
Operating Mode External Clock Mode
Recovery Time (nS) 100 (max)
Processing Shadow Time (nS) 200 (max)
Throughput Time (nS) 300 ns from external trigger
Data Ready The Data Ready output shall be inactive (TTL High)
Output Frequency Data Word The frequency data word shall be:
Frequency = (decimal word x 0.3 MHz) +1800 MHz
14 bit
Data Ready Output TTL high initially. TTL low when the
frequency data of input RF signal has
settled. Nominal pulse width
100 nanoseconds. After 100 ns, TTL releases
to high.
Power Supply (VDC) (Unit is protected from reverse polarity, transients, and turn-on sequence) +12 @ 200 mA
+8V @ 1.3 A
-8V @ 250 mA
Operating Temperature (Degree) -20 to +71 (higher temperatures available)
Size(Inches) 5.9 x 4.69 x 1.5
