Tuners

Tuner/Downconverter 6.0 - 18.0 GHz to 2.0 - 6.0 GHz Baseband

Features

    • TYPE 1 TUNER
    • 6.0 - 18.0 GHz INPUT FREQUENCY
    • 2.0 - 6.0 GHz IF OUTPUT
    • -10 dBm LO INPUT
    • 200 NS SWITCHING SPEED
    • 6.0 - 18.0 GHz AUXILIARY OUTPUT
    • -30 dBc INBAND SPURIOUS

Description

AKON’s A60-ML006 is a medium-gain downconverter which accepts inputs in the 6.0 to 18.0 GHz band, incorporates a 3-channel preselector filter, each channel being 4 GHz wide, and individually down converts those channels to a 2.0 to 6.0 GHz IF output. Conversion gain is roughly 12 dB, and dynamic range is 48 dB. 0 dB SNR threshold is -68 dBm. Deselected channel isolation is over 60 dB and switching time is less than 200 ns typical.

SPECIFICATIONS
Model Number A60-ML006
Frequency Range(GHz) 6.0 -18.0
IF Output (GHz) 2.0-6.0
Noise Figure (dB) 10 (max)
Switching Speed (nS) 200
Survival Power (W) 2 (max)
SP2T Switch Isolation (dB) 50 (min)
SP3T Switch Isolation (dB) 30 (min)
SP2T Controls (TTL) 2 bit
SP3T Controls (TTL) 2 bit ganged
LO Input (dBm) -10 (min)
VSWR 2.5:1 (max)
LO Radiation (dBc) -90 (max)
Aux RF Out Net Gain (dB) 12 +/- 1 dB in 6.0 - 14.0 GHz;
12 +/- 2 dB in 14.0 - 18.0 GHz
IF OUT Frequency Bandwidth (GHz) 2.0 - 6.0
IF OUT Net Gain (dB) 3 +/- 2 dB (6.0 - 14.0 GHz RF input) 3 +/- 3 dB (14.0 - 18.0 GHz RF input)
In Band Harmonics (dBc) <-30 (max)
In Band Spurious (dBc) <-30 (max)
IF Linear Dynamic Range (dB) 48 (min) (-68 dBm to -20 dBm)
Power Supply(VDC) +8.5, -8.5
Power Consumption (W) 8 (max)
