Tuner/Downconverter 2 - 6 GHz to 1 - 2 GHz Baseband

Features

    • TYPE 1 TUNER
    • 2.0 - 6.0 GHz INPUT FREQUENCY
    • 1.0 - 2.0 GHz IF OUTPUT
    • 25 dB IF OUT NET GAIN
    • HERMETIC PACKAGE OPTIONS AVAILABLE
    • EXCELLENT TEMPERATURE STABILITY
    • SIZE: 4.98” x 3.42” x 0.89”




Description

AKON’s A60-ML008 is a high gain downconverter which accepts inputs in the 2.0 to 6.0 GHz frequency band, incorporates a 4-channel preselector filter, each channel being 1 GHz wide, and individually down converts those channels to a 1.0 to 2.0 GHz IF output. Conversion gain is approximately 25 dB, and dynamic range is 52 dB. 0 dB SNR threshold is -72 dBm. Deselected channel isolation is over 60 dB and switching time is less than 200 nS typical.

SPECIFICATIONS
Model Number A60-ML008
Frequency Range(GHz) 2.0 -6.0
IF Output (GHz) 1.0-2.0
Noise Figure (dB) 10
Switching Time (nS) 200(for switch filter bank)
Survival Power (W) 2(max) CW or 200 (1% duty ratio)
SP3T Switch Isolation (dB) 50 (min)
SP4T Switch Isolation (dB) 30 (min)
SP3T Controls (TTL) 2 bit
SP4T Controls (TTL) 2 bit ganged
VSWR 2.5:1 (max) for all RF and IF ports
LO Input (dBm) -10 (min) (amplifier is used to meet the LO drive requirement)
LO Radiation (dBc) -90 (max)
Output Frequency Bandwidth (GHz) 2.0 - 6.0
Aux RF Out Net Gain (dB) 12 +/- 1
1 dB Compression Point (dBm) +12 at Output
Rejection For Input Less Than 1.7 GHz (dBc) -50 (min)
IF OUT Frequency Bandwidth (GHz) 1.0 - 2.0
IF OUT Net Gain (dB) 25 +/- 2
Rejection at IF Output Of 1.0 - 2.0 GHz (dBc) <-30(max) -60 <850 MHz
In Band Spurious (dBc) <-30 (max)
In Band Harmonics (dBc) <-30 (max)
IF Linear Dynamic Range (dB) 52 (min) (-72 to -20 dBm)
Input RF Power For 0 dB SNR at IF Output (dBm) -72
Power Supply(VDC) +12V / +8.5V @ 1.5A, -12V / -8.5V @ 300mA (max)
Operating Temperature (°C) -10 to +60
