Tuners

Microwave Assembly 1.0 - 18.0 GHz

Features

    • TYPE 1 TUNER
    • 65 dB INSTANTANEOUS DYNAMIC RANGE
    • -65 dBm CHANNEL SENSITIVITY
    • PRECONVERSION CHANNELS: 8 EACH;
    • -65 dBc; 15% FROM BAND EDGES
    • -60 dB CHANNEL TO CHANNEL ISOLATION
    • BUILT-IN 65 dB LOG VIDEO OUT @ 1.0GHz

Description

AKON is a leading manufacturer of high quality converter assemblies. Model A20-MX152 covers the 1.0 - 18.0 GHz input range. Using 8 pre-mixer channels and dual conversion, the input frequency is translated to 1.0 GHz with IF bandwidths of +/- 250, +/- 125, +/- 25 and extremely narrow +/-10MHz. Log Video (SDLA’s) at 1.0 GHz and 1.0 - 18.0GHz is built-in. Capability exists for the unit to receive an external signal of 750-1250 MHz and upconvert it to 1 - 18 GHz using unique architecture. AKON is qualified to MIL-I-45208 Quality System Requirements by agencies of the U,S, Department of Defense and well as by leading foreign and domestic military OEMs. Screening to requirements of MIL-STD-883 is available. All specifications described below are over the full operating temperature.



SPECIFICATIONS
Model Number A20-MX152
Frequency Range(GHz) Port J1 (Antenna) 1.0 - 18.0
Port J2 (Internal Connection) 1.0 - 18.0
Port J3 (BITE) 1.0 - 18.0
Port J9 (External Input) 0.75 - 1.250; -6 to +6 dBm
Port J11(LO1) 7.5 - 16.8; 0 dBm (max)
Port J12 (LO-2) 5.5; 0 dBm (max)
Noise Figure (dB) 17 (max); 16 (nom)
Dynamic Range(dBm) -65 to 0 (1.0 dB compression)
Input Pre-Selection CH:1
Frequency: 1.0 - 1.8 GHz
Stop-Band (-60 dBc): DC - 850 GHz; 2.07 to 18.0 GHz

CH:2
Frequency: 1.5 - 2.3 GHz
Stop-Band (-60 dBc): DC - 1.3 GHz; 2.64 to 18.0 GHz

CH:3
Frequency: 2.0 - 3.8 GHz
Stop-Band (-60 dBc): DC - 1.73 GHz; 4.37 to 18.0 GHz

CH:4
Frequency: 3.5 - 5.8 GHz
Stop-Band (-60 dBc): DC - 3.0 GHz; 6.3 to 18.0 GHz

CH:5
Frequency: 5.5 - 8.1 GHz
Stop-Band (-60 dBc): DC - 4.7 GHz; 9.315 to 18.0 GHz

CH:6
Frequency: 7.8 - 12.3 GHz
Stop-Band (-60 dBc): DC - 6.8 GHz; 14.14 to 18.0 GHz

CH:7
Frequency: 12.0 - 16.3 GHz
Stop-Band (-60 dBc): DC - 10.4 GHz; 18.745 to 24.0 GHz

CH:8
Frequency: 16.0 - 18.0 GHz
Stop-Band (-60 dBc): DC - 13.9 GHz
Port J5 Frequency Range: 1-18 GHz; +19 dBm (max); +13 dBm (min)
Port J6 Linear Receiver Gain: 5.0 dB Nom.
Output: -60 to +5 dBm
Frequency Ripple: +/- 2.0 dB
Frequency Flatness: +/- 3.0 dB (Including Temp.)
Port J7 (Band Limited) Output: -2 dBm +/- 2.0dB @750 - 1250MHz
Harmonics: -50 dBc
Port J8 (Band limited) Output: +7dBm +/- 2dB @750 - 1250 MHz
Harmonics: -50 dBc
Port J10 (Log Video Output) Frequency: 0.75 - 1.25 GHz
Dynamic Range: -65 to 0 dBm
Rise Time: 10 nS
Fall Time: 75 nS
Log Linearity: +/- 1.0 dB
Localized DLVA Flatness: +/- 1.0 dB (nom)
Port J13 (SDLA) Frequency Range: 750 MHz-18.0 GHz
Dynamic Range: -65 to 0 dBm
Log Linearity : +/- 1.0 dB (nom); +/- 2.0 (max)
Localized Flatness: +/- 2.5 (dB)
Rise Time: 10 nS
Recovery Time: 100 nS
Log Slope: 25 mV/dB
IF Bandwidth Center Frequency: 1.0 GHz
BW1: +/- 10 MHz
BW2: +/- 25 MHz
BW3: +/- 125 MHz
BW4: +/- 250 MHz
Digital Attenuator Frequency Range (GHz): 1.0 - 18.0 +/- 1.0 (nom)
Response Time: 100 nS
Dynamic Range: 15.5 dBm
Accuracy: +/- 1.0 dB
Step Size: 0.5 dB
Power Supply(VDC) +8 @ 2800 mA; -8 @ 700 mA
Power Consumption (W) 28
