Tuners

Four Channel 0.5 - 18.0 GHz ESM System Converter

Features

    • 0.5 - 18.0 GHz FREQUENCY RANGE
    • FOUR IF OUTPUTS
    • 1.0 GHz IF CENTER FREQUENCY
    • 100 ns SWITCHING TIME
    • EXTERNAL VARIABLE LO
    • BUILT-IN LO1 PROCESSING
    • BUILT-IN LO2
    • INTEGRATED DC-DC CONVERTER/ POWER SUPPLY
    • LO PRESENCE MONITOR
    • CHANNEL TEMPERATURE MONITORING
    • MODULAR DESIGN

Description

AKON’s A20-MX209 is a compact four channel tuner system that provides RF to IF conversion, pre-selection, and gain equalization. The modular design consists of 4 tuners, which each tuner handling 2 input bands from 0.5 - 18.0 GHz and 1 IF output at 1 GHz (single RF input from 0.5 - 18.0 also available) and features built-in LO1 amplification, filtering and multiplication using “high side” LOs. The unit also features an integrated DC-DC converter and LO presence and channel temperature monitoring.

SPECIFICATIONS
Model Number A20-MX209
Frequency Range(GHz) 0.5-18.0
Number of Input Channels 2 (0.5 - 8.0, 8.0 - 18.0 GHz)
Input Impedence (Ohms) 50 (nom)
RF Power Levels (dBm) -75 to -10
Recovery Time (µS) 1 (max)
IF Output Channels 4
IF Center Frequency (GHz) 1
IF Bandwidth (MHz) 500 +/- 250 @ 1 GHz Fc
Preselector Filter Rejection (dBc) -60 +/- 15% Fc
IF Output Power (dBm) +28 (max)
1 dB Compression Point (dBm) +21 (min)
Third Order Intercept (dBm) +30 (min)
Output VSWR 1.5:1 (max)
Channel to Channel Isolation (dB) 60 (min)
Gain (dB) +25 (nom)
Noise Figure (dB) 10 (nom); 11 max (below 8 GHz)
11 (nom); 12 max (above 8 GHz)
Spurious Levels (dBc) -60 (max)
Switching Time (nS) 100 (max)
Power Supply(VDC) +12 +/- 3%
Power Consumption (W) 70
Size(Inches) 9.95 x 4.74 x 3.55
