Switches

RF & Microwave Switches

Features

    • Low Insertion Loss
    • High Isolation
    • Wide Band Frequency Coverage
    • Compact and Ruggedized Packaging
    • Package Options: Drop-In, SMA/2.9mm & SMP

Description

AKON’s product line of RF & Microwave Switches that operates over a frequency range of 0.5 - 40 GHz. These switches are available in standard configurations such as SPST through SP6T with single ended TTL control. Our SP2T switches have a typical Insertion Loss of 1.2 - 1.8 dB, Isolation of 65 dB, and switching speeds of 40 nsec. Package options include Drop-In, SMA/2.9mm & SMP, and offers reflective/absorptive configurations.

AKON products are designed to withstand harsh environments of Military, Space and Industrial applications. Our compact and ruggedized products are designed to handle harsh mechanical shock/vibrations, temperature cycling, altitude and temperature extremes.

Reliability is a key feature of AKON products and to ensure this we perform ESS testing on all of our products. AKON offers an off-the-shelf screening option called its “H“ series, per Mil-STD-883 level B that is available on all of its RF & Microwave Components. For custom electrical, mechanical, and screening options, please contact AKON Sales: sales@akoninc.com (or) 408-432-8039.

Model Number Frequency (GHz) Insertion Loss (dB) Isolation (dB) VSWR Switching Speed (nS) Bias (+ VDC) Control Input Power Handling (dBm) Pkg. EAR99/ ITAR Select Product
A35-MH208 0.5-4 1.1 60 1.8:1 50 +5, -12 TTL 24 D, C, S EAR99
A35-MH209 0.5-8 1.4 60 1.8:1 50 +5, -12 TTL 24 D, C, S EAR99
A35-MH2010 0.5-12 1.4 60 1.8:1 50 +5, -12 TTL 24 D, C, S EAR99
A35-MH2011 0.5-18 1.9 60 1.8:1 50 +5, -12 TTL 24 D, C, S EAR99
A35-MH2012 0.5-20 2.4 60 1.8:1 50 +5, -12 TTL 24 D, C, S EAR99
SP2T
A35-MH2013 0.5-4 1.3 60 1.8:1 50 +5, -12 TTL 24 D, C, S EAR99
A35-MH2014 0.5-8 1.8 60 1.8:1 50 +5, -12 TTL 24 D, C, S EAR99
A35-MH215 0.5-12 1.8 60 1.8:1 50 +5, -12 TTL 24 D, C, S EAR99
A35-MH216 0.5-18 2.3 60 1.8:1 50 +5, -12 TTL 24 D, C, S EAR99
A35-MH217 0.5-20 2.8 60 1.8:1 50 +5, -12 TTL 24 D, C, S EAR99
A35-MH206* 1-18 4.3 65 2.0:1 50 +5, -12 TTL 20 D, C, S EAR99
A35-MH139 2-18 3 60 2.0:1 50 +/- 5 TTL 24 D, C, S EAR99
A35-MH207* 6-20 4.3 65 2.0:1 50 +5, -12 TTL 20 D, C, S EAR99
A35-MH205** 18-40 4.5 65 2.0:1 75 +5, -12 TTL 20 D, C, S EAR99
SP3T
A35-MH132 2-18 2.5 60 2.0:1 50 +/- 5 TTL 24 C, S EAR99
SP3T - SP2T
A35-MH138 2-18 3 60 2.0:1 50 +/- 5 TTL 30 C, S EAR99
SP4T
A35-MH202* 1-18 4.3 65 2.0:1 50 +/- 5 TTL 20 C EAR99
A35-MH133 2-18 4.4 60 2.0:1 50 +/- 5 TTL 24 c EAR99
A35-MH203* 1-18 4.3 65 2.0:1 50 +/- 5 TTL 20 C EAR99
SP5T
A35-MX195 2-18 3 70 2.0:1 50 +/- 5 TTL 24 C EAR99
A35-MH137 2-18 4 60 2.0:1 50 +/- 5 TTL 24 S EAR99
SP6T
A35-MH204* 1-18 6 65 2.0:1 75 +5, -12 TTL 20 C EAR99
A35-MH134 2-18 6 55 2.0:1 50 +5, -12 TTL 24 C EAR99
Note: You can select different models and submit inquiry or custom quote request with help of different options available at bottom of page.

AKON, Inc. and it’s affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
All products are measured in 50-ohm system, over a temperature Range of -54° to +85° C.
*Absorptive Design; **Uses 2.9mm connectors
Note: Packaging Options: D = Drop-In , C = F-SMA, S = SMP (Model Number Example: A35-MH143D)
