Tuners

0.4 - 18.0 GHz Pre-Channelized Single Conversion, IF B.W 2.0-6.0 GHz Miniature Tuner

Features

    • TYPE 2 TUNER
    • 0.4 - 18.0 GHz INPUT FREQUENCY RANGE
    • PRE-FILTERED TO AVOID HARMONICS
    • 2.0 - 6.0 GHz OUTPUT
    • 21 dB TOTAL GAIN
    • OUTPUT AMPLIFIER WITH +20 dBm OUTPUT POWER
    • SIZE: 6.8” x 5.1” x 1.0”

Description

?AKON’s A20-MX084 us an ultra wideband, three input 0.4 - 18 GHz combination up and down converter. Signals in the 0.4 to 2.0 band pass through a two channel filter preselector, and these channels are individually upconverted into the 2 to 6 GHz band. Signals in the 2 to 6 GHz band pass through the unit without frequency conversion, only amplification. Signals in the 6 to 18 GHz band pass through a three channel filter preselector and are then individually downconverted to the 2 to 6 GHz band. Input NF is band dependent and varies from 8.5 to 12 db. Conversion gain is 21 dB typical, and deselected channel isolation is typically 60 dB.

Model Number A20-MX084
Frequency Range(GHz) J1: 0.4 - 2.0
J2: 2.0 - 6.0
J3: 6.0 - 18.0
LO Input (dBm) J5: +20 (typ)
Harmonics: -40 dBc (max)
Spurious: -60 dBc (max)
RF Frequencies and Corresponding LO Frequencies (GHz) RF LO
0.4 - 1.0 6.4
1.0 - 2.0 6.4
6.0 - 10.0 12.0
10.0 - 14.0 16.0
14.0 - 18.0 12.0
Gain, Gain Flatness (dB) 21 (nom), (+/- 3 (max) , +/- 2 (85% BW))
VSWR 2.0:1 (nom); < 3.0:1 (95% BW)
Harmonics (dBc) Pre-mixing > 60; Post-mixing -35 (nom)
Image Rejection/Spurious (dBc) RF Band dBc
0.4 - 2.0 -40
2.0 - 6.0 -40
6.0 - 10.0 -38
10.0 - 14.0 -40
14.0 - 18.0 -40
Input 1 dB Compression (dBm) J1: -2 (typ)
J2: -3 (typ)
J3: -4 (typ)
Power Supply(VDC) +12 @ 1.7A (max)
-12 @ 0.4A (max)
Noise Figure (dB) J1: 10.5 (max)
J2: 8.5 (max)
J3: 12.0 (max)
Isolation (dB) 60 (min)
Filter Rejection(dBc) -60 @ 15% From Band Edges
