Switch Matrices

0.5 - 18.0 GHz Switch Matrix (16 x 12)

Features

    • 0.5 - 18.0 GHz Frequency Range
    • +/- 8° deGREES Phase Tracking
    • 15 dBm Operating Input Power
    • 50 nS Switching Speed (10/90% RF)
    • -40 C° to +71 C° Operating Temperature

Description

AKON’s Model No. A35-MX141 is an absorptive switch matrix consisting of 36 RF input/output connectors with two SP18T absorptive RF switches as the basic building blocks. Using a single RFconnector, it allows either a transmitter or receiver to connect to 36 different array elements. Phase matching of +/- 8º is from any of the 16 input ports to any of the 12 output ports. The input signals are launched through a precision, high performance 2.0 dB attenuator and a mechanical adjustable phase shifter. The unit is fed using a phase matched cable to an Integrated Microwave Assembly (IMA). Microwave Assembly consists of SP5T (70 dB isolation), a medium power, low noise amplifier, a VVA for temperature compensation of amplifier and switch circuits.

SPECIFICATIONS
Model Number A35-MX141
Frequency Range(GHz) 0.5 - 18 (J21, J40 to J55, J56 to 59);
0.5 – 2.0 (P9 to P12);
6.0 – 18.0 (P13 to P16);
2.0 – 6.0 (P17 to P20)
Operating Input Power (dBm) -60 to +8;-40 to -20 (max) (P21 CAL Input)
Gain/Loss Flatness (dB) -5 (nom) (J40 to J55 to P9 to P20);
-12 (nom) (P21 to P9 to P20);
-11 (max) (P21 to J58 to J59);
+20 (min) (P21 to J56 to J57)
Noise Figure (dB) 11 (J4 to J55 to P9 to P20);
16 (P21 to P9 to P20);
12 (P21 to J58, J59);
13.5 (P21 to J56, J57)
Gain Window (dB) +/- 3.5
1dB Compression point (J40 to J55) (dBm) +8 (min);
+9 (nom)
Phase Matching Between Ports (°C) +/- 8 over frequency and temperature
Input Signal Type CW/ Pulsed
Pulse Width Range (nS) 0.1 μSec - 250 μSec
Input PRI Range (uS) 1-5000
Maximum Input Level (dBm) +15.0 CW
Isolation (SP5T and SP3T) (dB) 70(min)
Switching Speed (nS) < 50
VSWR (at all RF ports) 2.0:1 (max)
Power Supply(VDC) +28 V +/- 5% @ 1.2 Amps
Operating Temperature (°C) -40 to +71
