SDLVAs

Compact RF & Microwave High Speed SDLVAs

Features

    • Wide Frequency Range Coverage 2-18 GHz
    • Excellent Log Linerity over -70 to 0 dbm
    • Fast Rise Time of ≤ 10 ns
    • Fast Recovery Time of ≤ 60 ns
    • Compact and Ruggedized Packaging
    • EAR 99 Export Classification

Description

 AKON’s new Compact RF & Microwave High Speed SDLVAs operate over a frequency range of 2-18 GHz range from -70 to 0 dBm input power range. These new Compact RF & Microwave High Speed SDLVAs utilize the latest thin-film microelectronics hybrid technology, making it well suited for harsh military, industrial & space markets.

AKON products are designed to withstand the demanding environments of Military, Space and Industrial applications. Our compact and ruggedized products are designed to handle stringent mechanical shock/vibrations, temperature cycling, altitude and temperature extremes.

Reliability is a key feature of AKON products and to ensure this we perform ESS testing on all of our products. AKON offers an off-the-shelf screening option called its “H“ series, per Mil-STD-883 level B that is available on all of its RF & Microwave Components. For custom electrical, mechanical, and screening options, please contact AKON Sales: sales@akoninc.com (or) 408-432-8039.



SPECIFICATIONS
Model Number A15-MH243 A15-MH244 A15-MH245
Frequency Range(GHz) 2-6 6-18 2-18
T.S.S. (dBm) -73 -73 -73
Logging Range (dBm) -70 to 0 -70 to 0 -70 to 0
Frequency Flatness(dB) +/- 1.5 +/- 2.0 +/- 2.0
VSWR 2.0:1 2.0:1 2.0:1
Log Linearity (dB) +/- 1.0 +/- 1.0 +/- 1.0
Log Accuracy (dB) (over termperature at a given frequency) +/- 2.5 +/- 3.0 +/- 3.0
Log Slope (mV/dB) For Linerity Measurement 25 25 25
Rise Time (nS) 10 10 10
Recovery Time (nS) (90% to +/- 1.0 dB of Baseline) 60 60 60
Propagation Delay (nS) (50% RF to 10% Video) 10 10 10
Power Supply Current (mA) +12 (VDC) 500 500 500
-12 (VDC) 150 150 150
Coupling DC DC DC
Video Load (ohms) 93 +/- 1 93 +/- 1 93 +/- 1
Size(Inches) 2.5" x 1.8" x 0.5" 2.5" x 1.8" x 0.5" 2.5" x 1.8" x 0.5"
Operating Temperature (°C) -20 to +85 -20 to +85 -20 to +85
Select Product
Note: You can select different models and submit inquiry or custom quote request with help of different options available at bottom of page.

AKON, Inc. and it’s affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
All products are measured in 50-ohm system, over a temperature Range of -20 to +85° C.
Note: All dimensions are specified in inches (mm)
